LOW LOSS Coaxial Wire
LOW LOSS Coaxial Wire
LOW LOSS Coaxial Wire
LOW LOSS Coaxial Wire

LOW LOSS Coaxial Wire

Use for wireless communications，broadcasting and radio frequency signals，etc.

keyword：

category：

Coaxial Cable

High Temperature Coaxial Cable

Product consultation：

+86-138-1769-1639

Product inquiry
Related products

Product Description

Electrical Property

Conductor Tensile Breaking

55N（Min）

Capacitance Conductor to Shield

86±5pF/m

Characteristic Impedance

50±3.5 Ω
Velocity of Propagation

76%

Bend Radius10mm
Voltage Rating1000VMS
Max. Operating Frequency

3000MHz

Operating temperature range

-55 ~ +200℃

Attenuation（20℃）

MHz

Attenuation≯(dB/m)

400

 0.670

1000

1.065

2450

1.745

60002.85
