High Temperature Coaxial Wire

Use for wireless communications，broadcasting and radio frequency signals，etc.

keyword：

High Temp Coax Cable

category：

High Temperature Coaxial Cable

Product consultation：

+86-138-1769-1639

Product inquiry

Related products

Product Description

RG COAXIAL CABLE

Conductor : Sliver copper
Insulation : PTFE
Jacket : FEP
Temperature Range : -55°C~+200°C
Colour : White-Transparent or other

Product Features:

Good resistance to electromagnetic interference and flexibility, not only lightweight, but also has characteristics such as high temperature resistance, moisture resistance, and corrosion resistance. It exhibits excellent electrical performance in shielding, attenuation, standing wave, and other indicators.
Contains no harmful substances and meets ROHS standards.
Application Scope:
Widely used in communications, aviation, smart robots, military, and other fields.

Type	Conductor Construction	Outer Diameter （mm）	Shield	Outer Diameter （mm）	Impedance Ω	MAX Frequency MHZ	Attenuation ≤d B/m	MAX Voltage VMS
RG178	7/0.102	0.86	SINGLE	1.90	50	3000	2.572	1000
RG316	7/0.18	1.52	SINGLE	2.5	50	3000	1.532	1200
RG316D	7/0.18	1.5	DOUBLE	2.95	50	3000	1.532	1200
RG393	7/0.8	7.24	DOUBLE	9.91	50	11000	1.089	5000
RG142	1/0.94	2.95	DOUBLE	4.95	50	5000	1.05	1900
RG141	1/0.94	2.95	SINGLE	4.83	50	5000	1.05	1900
RG304	1/1.5	4.7	DOUBLE	7.11	50	5000	0.755	3000
RG179	7/0.102	1.52	SINGLE	2.5	75	1000	0.869	1200
RG302	1/0.64	3.71	SINGLE	5.13	75	3000	0.666	2300
RG303	1/0.94	3.0	SINGLE	4.3	70	3000	0.781	1900
RG180	7/0.102	2.59	SINGLE	3.56	95	1000	0.676	1500
RG400	19/0.203	3.0	DOUBLE	4.95	50	11000	1.899	1900
RG188	7/0.18	1.5	SINGLE	2.55	50	3000	1.532	1200
